Wireless mode

IEEE 802.11b/g/n (Wi-Fi 4)

Wi-Fi security

WPA2-EAP/WPA3-EAP Mixed Mode, WPA3-EAP, WPA2-PSK/WPA3-SAE Mixed Mode, WPA3-SAE, OWE, WPA-PSK/WPA2-PSK Mixed Mode, WPA2-PSK, WPA2-EAP; AES-CCMP, TKIP, Auto Cipher modes, client separation

SSID/ESSID

SSID stealth mode and access control based on MAC address

Wi-Fi users

Up to 100 simultaneous connections

Wireless mesh/roaming

Fast roaming (802.11r)

Wireless MAC filter

Whitelist, blacklist

Ethernet

1 x RJ45 port 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover

Network protocols

TCP, UDP, IPv4, IPv6, ICMP, HTTP, HTTPS, SSL v3, TLS, ARP, SSH, DHCP client, SMNP

Authentication

Pre-shared key, digital certificates, X.509 certificates, TACACS+, Radius, IP & Login attempts block

VLAN

Tag based VLAN separation

WEB UI

HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, event log, system log, kernel log

FOTA

Firmware update from server, automatic notification

SSH

SSH (v1, v2)

SNMP

SNMP (v1, v2, v3), SNMP Trap

JSON-RPC

Management API over HTTP/HTTPS

RMS

Teltonika Remote Management System (RMS)

CPU

Mediatek, 580 MHz, MIPS 24KEc

RAM

64 MB, DDR2

FLASH storage

16 MB, SPI Flash

WEB UI

Update FW from file, check FW on server, configuration profiles, configuration backup

FOTA

Update FW

RMS

Update FW/configuration for multiple devices at once

Keep settings

Update FW without losing current configuration

Operating system

RutOS (OpenWrt based Linux OS)

Supported languages

Busybox shell, Lua, C, C++

Development tools

SDK package with build environment provided

Connector

RJ45 Socket

Input voltage range

44.0 – 57.0 V

PoE standards

802.3af PoE Class 1

Power consumption

< 2 W Max

Ethernet

1 x RJ45 ports, 10/100 Mbps

Status LEDs

1 x Power LED (can be turned off from web-UI)

Antennas

2 x Internal for 2.4 GHz Wi-Fi

Reset

Reboot/User default reset/Factory reset button

Casing material

UV stabilized plastic

Dimensions

Ø 158 mm x 30 mm

Weight

190 g

Mounting options

AP Mounting Bracket (for ceiling mount)

Operating temperature

-40 °C to 75 °C

Operating humidity

10% to 90% non-condensing

Ingress Protection Rating

IP30

Regulatory

CE, UKCA, CB, FCC, IC, WEEE

Standards

EN 55032:2015+A11:2020

EN 55035:2017+A11:2020

EN 61000-3-3:2013+A1:2019+A2:2021

EN IEC 61000-3-2:2019+A1:2021

EN 301 489-1 V2.2.3

EN 301 489-17 V3.2.4

ESD

EN 61000-4-2:2009

RS

EN IEC 61000-4-3:2020

EFT

EN 61000-4-4:2012

Surge protection

EN 61000-4-5:2014+A1:2017

CS

EN 61000-4-6:2014

DIP

EN IEC 61000-4-11:2020

Standards

EN 300 328 V2.2.2

Standards

IEC 62368-1:2018

EN IEC 62368-1:2020+A11:2020

EN IEC 62311:2020
